Two heads are better than one. The same can be said for microphone inputs, especially when it comes to live streaming. The AG06MK2 offers the same user-friendly configuration and operation that has become synonymous with the AG series, but also comes equipped with two phantom-powered mic inputs for condenser microphones. Combined with flexible connectivity, including an upgraded 4-pole mini I/O, the AG06MK2 opens a broader range of dialogue, interview, musical ensemble performance, or other streaming applications that the AG01 or AG03MK2 setups can't cover.
Features
• Two condenser microphones can be used simultaneously
• +48 V phantom power on CH1-2 input for condenser mics or Dl boxes
• Hi-Z input for guitars on CH2
• High resolution (24-bit, 192 kHz) 2-track audio recording and playback
• 4-pole mini input/output (TRRS) to support a wider range of streaming applications
• Flexible inputs and LOOPBACK function ideal for live streaming or recording
• Mute button for convenient live streaming
• Easy control and pro sound with 1-TOUCH effects (COMP/EQ, REVERB and Amp Simulator)
• AG Controller (Windows/Mac/iOS ) for precise parameter control
• Windows/Mac support by USB-C connection
• iOS connectivity via Apple camera adaptor (requires external USB power supply)
• Android supported by 4-pole mini input/output (TRRS)
• USB-C power input (5 V DC, 900 mA)
• Cubase Al, WaveLab Cast, Cubasis LE and Rec'n'Share are available
Specifications
Input Channels:
- Mono[MIC/LINE]: 2 - CH1: Combo (Mic, +48 V phantom power / Line), 3.5 mm (1/8") stereo mini (Headset mic, Plug-in power), CH2: Combo (Mic, +48 V phantom power / Guitar input / Line)
- Stereo[LINE]: 2 - L/R Stereo: Phone, RCA
- Smartphone: 1 - PHONES / HEADSET PHONES *Cannot be used simultaneously
- USB: 1
Output Channels:
- PHONES: 2 - PHONES / HEADSET PHONES
- Smartphone: 1 - 4-pole mini input/output (TRRS)
- MONITOR OUT: 1
- USB: 1
Bus: 1 Stereo
Functions:
- MUTE button x 1
- PAD button x 2
- HI-Z button x 1
- STREAMING OUT (DRY CH 1-2G / INPUT MIX / LOOPBACK)
- MIX MINUS MIC (ON / OFF)
Power requirements: 5 V DC, 900 mA
Power consumption: Max. 4.5 W
Dimension WxHxD: 152 x 63 x 201 mm
Weight: 0.9 kg
