The So-Cal ash body is coupled with a pickguard, bolt-on maple neck featuring a pair of graphite-reinforcement rods to resist bending and warping under environmental stresses. The speed neck profile is designed for lightning fast playing and completely unhindered position shifts, while the comfortably rolled fingerboard edges provide the broken-in feel of an instrument with plenty of playing miles on it, and plenty more to go. Perfect for faster tempos, the 12"-16" compound radius fingerboard hosts 22 jumbo frets and dot inlays. For regularly touring musicians, a heel-mount truss rod adjustment wheel is a must, allowing for quick and convenient neck relief tweaks.
Hot-rodded for unparalleled performance and sound, this instrument hosts a high-output Seymour Duncan® Distortion TB-6 humbucking bridge pickup and a warm, fat Seymour Duncan Distortion SH-6N humbucking neck pickup.
The volume control hides a push/pull coil split for even more highly useful tonal variations, ideal for everything from a biting lead sound to thick, chunky rhythm work. The no-load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound that lets the full natural voice of the guitar shine through. A Charvel HT6 string-through-body hardtail bridge is designed for improved intonation and enhanced sustain and resonance.
Specifications
General
Series: Pro-Mod
Orientation: Right-Hand
Country Of Origin: MX
Neck
Headstock: Licensed Fender® Stratocaster®
Neck Material: Maple
Neck Finish: Hand-Rubbed Satin Urethane
Neck Construction: Bolt-On with Graphite Reinforcement
Fingerboard Radius: 12" to 16" Compound Radius (304.8 mm to 406.4 mm)
Fingerboard Material: Rosewood
Position Inlays: White Dot
Side Dots: White
Frets: 22 Jumbo
Truss Rod: Dual-Action Head Adjust
Truss Rod Nut: Heel-Mount Truss Rod Adjustment Wheel
String Nut: Black Plastic
Nut Width: 1.6875"
Nut Material: Black Plastic
Scale Length: 25.5" (64.77 cm)
Body
Body: Alder
Body Finish: Satin
Body Shape: So-Cal Style 1
Body Material: Alder
Hardware
Bridge: Charvel® HT6 String-Through-Body Hardtail
Pickguard: 1-Ply Black
Pickup Covers: Black
Hardware Finish: Black
Tuning Machines: Charvel® Sealed Die-Cast Locking
Strings: Nickel Plated Steel (.009-.042 Gauges)
Strap Buttons: Standard
Electronics
Bridge Pickup: Seymour Duncan® Distortion™ TB-6
Neck Pickup: Seymour Duncan® Distortion™ SH-6N
Pickup Configuration: HH
Controls: Volume (Push/Pull Coil Split), Tone
Switching: 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup - (Split Engaged) - Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil
